EOTech 552.A65/1 Military HOLOgraphic Weapon Sight



List Price : $549.00 Price :
EOTech 552.A65/1 Military HOLOgraphic Weapon Sight

Product Description

The HDS uses state-of-the-art digital electronics design. Twenty brightness levels ensure proper brightness control in either low light or very bright sunlight. An on-board microprocessor provides automatic battery check indicator, up/down brightness scrolling and programmable auto shutdown features. All electronics are fully encapsulated in shock absorbing resin compound.OperationOptics: Transmission holography - 100% parallax freeMagnification: 1x unlimited eye reliefTemperature:-20 to 150F (operating); -40 to 160F (storage)Sealing: Waterproof (submersible) & fogproofColor/Finish: Non-reflective black with hard coat finishAdjustment (per click): 0.5-Inch at 100 yardsAdjustment Range: +/- 40 MOA travelMount: 1-Inch Weaver dovetail/Picatinny rail (Mil spec 1913)Return to Zero: Repeatable to 1 MOA after remountingHeads-Up Display Window Optical Surfaces: Anti-glare and scratch resistant coatingsWindow Dimensions: 1.20-Inch x 0.85-Inch (30 x 23 mm)Window Material: Shatterproof laminate (3/16-Inch thick)Field of view (100 yards): 30 yards (28m) at a 4-Inch eye reliefStandard Reticle: 65MOA ring with quadrant ticks with a 1MOA Aiming dotReticle Contrast Ratio: 28,000:1 brightest to lowestNight Vision Contrast Ratio: 10,000,000:1 with NV switch engagedElectrical Power Source: 2 x -InchN-Inch alkaline batteries (available anywhere)Battery Life: 70 hours at nominal setting 12 (AA batteries: 350 hrs)Brightness Settings: 20 settings with scrolling featureAuto Battery Check Indicator: Flashing reticle upon startup if batteries are at 20% of battery life.Auto Shutdown: At 8 hours - programmable to 4 hours-Model 550 AA-Order code 552.A65/1-Night Vision Compatible -Waterproof & Submersible To 33 ft depth -Battery AA Alkaline-Battery Life 900 hours continuous-Length of sight54 inches (131 mm)-Reticle Options 65 MOA ring w/ 1 MOA dot-Weight: 8.8 ounces (250 grams)

Amazon.com

Standardized by the DEA, ATF, and FBI SWAT team, the Model 552 holographic weapon sight is the sight of choice for such military units as the Stryker Brigade, 10th Mountain, and 3rd Infantry. The Model 552 sports a revolutionary sighting system based on advanced holographic technology. The design works by using laser light to illuminate a holographic pattern embedded in the heads-up display window. When the shooter looks through the window, he or she will see a virtual red image of a reticle pattern projected onto the target plane. Overall, the holographic sight improves target acquisition, boosts accuracy, and increases control over the shooting environment.

The Model 552 is built to last, with a rugged aluminum hood assembly and knobbed, tool-free mounting bolt. The battle-proven design can withstand the abuse that any harsh environment, high-powered weapon platform, or military mission can dish out. Other features include a 65 MOA ring reticle with a 1 MOA aiming dot; support for two 1.5-volt AA batteries (lithium or alkaline); unlimited eye relief; and 30 brightness settings. The Model 552 is compatible with Gen I-IV night vision systems and mounts on 1-inch Picatinny or Weaver rails.

Specifications

  • Optics: Transmission holography, parallax-free
  • Magnification: 1x
  • Eye relief: Unlimited
  • Waterproof: Submersible to 33 feet
  • Sealing: Fogproof internal optics
  • Adjustment (per click): 0.5 MOA (1/2 inch @ 100 yards)
  • Adjustment range: +/- 40 MOA travel
  • Mount: 1-inch Picatinny or Weaver rail
  • Return to zero: Repeatable to 1 MOA after remounting
  • Display window optical surfaces: Anti-glare coating
  • Window dimensions: 1.2 by 0.85 inches
  • Front window material: 1/8-inch solid glass
  • Rear window material: Shatter-resistant laminate (3/16 inches thick)
  • Field of view: 30 yards @ 100 yards at 4 inches eye relief
  • Brightness adjustment range: 146,000:1 (brightest to lowest)
  • Night vision compatibility: 1280:1 with NV switch engaged
  • Power source: Two 1.5-volt AA batteries (supports lithium, alkaline, or rechargeables)
  • Battery life: 1,000 continuous hours (lithium) at nominal setting; 600 continuous hours (alkaline)
  • Brightness settings: 30 with scrolling feature (10 settings for NV use)
  • Auto battery check indicator: Flashing reticle upon startup
  • Auto shutdown: At 8 hours; programmable to 4 hours
  • Dimensions: 5.4 by 2.25 by 2 inches (W x H x D)
  • Weight: 10.9 ounces


  • Holographic sight designed for close-in combat speed and versatility
  • Uses laser light to illuminate holographic red reticle projected on target plane
  • Improves target acquisition, boosts accuracy, and increases control
  • Rugged aluminum hood assembly; knobbed, tool-free mounting bolt
  • Requires 2 AA batteries; supports 1-inch Picatinny or Weaver rails


EOTech 552.A65/1 Military HOLOgraphic Weapon Sight Reviews


EOTech 552.A65/1 Military HOLOgraphic Weapon Sight Reviews


Amazon.com
Customer Reviews
Average Customer Review
10 Reviews
5 star:
 (8)
4 star:
 (2)
3 star:    (0)
2 star:    (0)
1 star:    (0)




36 of 36 people found the following review helpful
4.0 out of 5 stars Top Notch Bit of Kit, November 22, 2007
By
G. Lester (Pennsylvania) - See all my reviews
(REAL NAME)
Before purchasing my first electronic weapon sight I had the great fortune of being able to compare side-by-side the EOTech 550 with an Aimpoint Comp M2 and a Zeiss Z-point. For me EOTech was the hands-down winner. I have a significant astigmatism and both the Aimpoint and Zeiss electronic dots appear more like an indistinct bunch of grapes than a single aiming point. No such problem with the EOTech at all but the highest two or three power settings. The EOTech aiming point also includes a larger illuminated circle around the central dot. In my experience I use the large dot for fast, close-in shooting and utilize the small 1MOA dot for deliberate precision shots at a distance. With this sight I have the best of both worlds. I also like the universal availability of AA batteries. This was always an issue with most other electronic sights, since they typically use power cells no where near as popular as the AA. This is obviously an issue since Aimpoint recently began production of an... Read more
Help other customers find the most helpful reviews
Was this review helpful to you?  Yes No


33 of 33 people found the following review helpful
5.0 out of 5 stars For Afghanistan, March 8, 2011
This review is from: EOTech 552.A65/1 Military HOLOgraphic Weapon Sight (Sports)
The only reason i got this sight is because my M68/CCO Aimpoint is not reliable at all.At the base of the sight it is screwd into the mount with an allen wrench screw, Or atleast the comp4s are.And when i needed it most the damn thing bounced off the rifle. The screw came loose and fell off. That was the second time that happend. Iam sorry but i cant put my life into an aimpoint. They have lost my trust. Eotech on the other hand is great. I fell in love with it the first day i got it. I trust it with my life. Very sturdy and comes with option of allen screw or twist screw. Very easy to operate and reliable. I would recommend it to my own men. Its just that good.

US Army Infantry rifleman.
10th Mountain Div (LI)
3rd BCT
Attack company 1-32inf (Chosin)
2nd Platoon
Help other customers find the most helpful reviews
Was this review helpful to you?  Yes No


16 of 17 people found the following review helpful
5.0 out of 5 stars EOTech 552.A65, March 4, 2011
By
This review is from: EOTech 552.A65/1 Military HOLOgraphic Weapon Sight (Sports)
Never knew what I was missing until I purchased the EOTech 552.A65. The sight works best with both eyes open. It's almost impossible to miss your target even at 300 meters. The best way to sight this in is to hit dead center at 50 meters and you will be right on at 200 meters, and 1 inch high at 100 meters. and 1.5 inches low at 300 meters with a 55gr to 60gr bullet.
Help other customers find the most helpful reviews
Was this review helpful to you?  Yes No


Share your thoughts with other customers:
›  See all 10 customer reviews...
